Omega Cranks RF ISIS

Regular price €67,00 EUR
Sale price €67,00 EUR Regular price
Shipping calculated at checkout.
In stock
Size
Q-factor
Which Q-profile do I need?

Some bikes need different left and right crank profiles. Match the complete codes on both existing cranks, including any prefixes or suffixes.

See the illustrated Q-factor guide
Omega RF ISIS Crank Arms. Cold-forged aluminium construction. Choose crank length and Q-profile for your ISIS setup.
View full details

MIRANDA / CRANKS & CRANKSETS

Made in Portugal from cold-forged aluminium, the Omega is built around Miranda crank geometry for a correctly matched drivetrain. Choose your length and check the complete arm profile before replacing your existing pair.

At a glance

  • Cold-forged aluminium crank construction
  • Match length and geometry to your existing assembly
  • RF version: use the complete geometry code when matching your pair

Technical details

Product specifications
Material Cold-forged aluminium
Interface / application ISIS
Crank lengths (mm) 160, 170
Crank geometry options Q:16
Supplied as Left and right crank arms, with installation screws

Choose the right setup

Match the drive-unit interface first, then choose the crank length and complete Q-profile. Miranda Q codes identify crank geometry; they are not the total Q-factor of the assembled bike. Check frame clearance and left/right geometry before installation.

Compare configurations and product codes
Configuration Product code
160 / Q:16 PO02IBT17CA70000S141
170 / Q:16 PO01IBT17CA70000S142

Technical drawings and installation guides

Videos and technical guides

Specifications

EAN
5603895456751
Crank length (mm)
160
Crank geometry
Q:16
interface
ISIS
Material
Aluminium
segment
E-bike, MTB, City & Trekking
